Application fields: Passive speaker connections / sound reinforcement / studio installation / live
Conductors: Bare copper 14 AWG = 48×0,25 mm – O.F.C.
Lay up: four conductors twisted in short concentric layers
Insulation: flexible PVC 3,45 mm
Jacket: Ultra – Flexible PVC – 60 Shore
Overall diameter: 11,00 mm
Cable section: 2,5 mm2/AWG14
Electrical Resistance @ 20°C: 7,4 Ohm/Km (conductor)
Electrical Capacitance @ 1 KHz: 85 pF/mt (conductor/conductor)
Operating temperature: -20°C / +70°C
Minumum bending radius: 10 x overall diameter
Weight: 204 Kg/Km
Color: Black
Packaging: 100 m wooden reel
