Tecnare ALIS12 Point Source Loudspeaker

2-Way Bi-amped Enclosure

1 x 12-inch neodymium LF cone drive, vented box

1 x 1.4-inch exit (3-inch voice coil) compression driver, attached to a waveguide

2.000

The exceptional scalability and the ability to form small arrays of two, three or four cabinets with strict control of dispersion makes ALIS12 capable of adjusting to any audience geometry, being the ideal choice for distributed systems in sports venues. Arrays can be flown horizontally or vertically, or stacked when needed. ALIS12 show no angle settings to calculate or spread adjustments to implement for each show, as these is already fixed. Tecnare’s DP4896 and DP2696 processors provide presets for ALIS12 arrays to quickly optimize your system. With the Ease Focus 2 acoustical prediction program you can create accurate acoustic simulation. ALIS12 offer unbeatable audio performance for all kind venues, where polar control, high-output, lowdistortion, and the highest quality sound are required. Constructed of premium WISA birch plywood, ALIS12 enclosure are covered with a hard-shell finish coating. Rigging is made out of aluminum to lower weight and optimize weatherization. ALIS12 can be sold in passive version.
  • Exceptional size-to-power ratio; easily powerful enough to use for main system, delay stacks, or fill duties
  • 1 x 12-inch-LF cone driver / 1 x 1.4-inch exit (3-inch voice coil) HF compression driver coupled to a waveguide
  • Plug-and-play package, quick set-up and easy flying

Applications

  • Theatres and theatrical sound reinforcement
  • Stand alone system
  • Center and Sidefill applications
  • Concert Halls, distributed systems and clubs
Frequency Response: 55 Hz – 20 kHz ±4dB, measured on axys
Components: 1×12” neodymium LF driver, 3” voice coil, 1×1.4’’ exit compression driver
Nominal Dispersion: 20º x 75° @-6dB
Impedance: LF: 8 Ohm / HF: 16 Ohm
Axial Sensitivity: 104 dB
Calculated SPL: 131 dB nominal / 137 dB continuous
Power Handling: 710 W AES / 1400 W continuos

             *LF power: 600W AES @8ohm

             *HF power 110W AES @16ohm

Dimensions (HxWxD) (millimeters/inches): 654,5 x 388 x 582,6 mm / 25.77″ x 15.27″ x 22.94″
Net Weight (kg/Pounds): 33,5 Kg / 73.85 lbs
Construction: 16mm birch plywood. Finished in black semi-matt textured Polyurea weatherized coating. One recessed by side carrying handle.
Grille:  Powder coated perforated steel with acoustically transparent reticulated foam.
