2 Channels
APA-5200 2 x 2600W at 4 ohms
APA-5200 2 x 1400W at 8 ohms
5200W 8Ω bridge mono
€1.650,00
APA Series analog amplifiers from Tecnare Sound Systems, the perfect solution for those who demand the highest audio quality in their sound systems.
| Rated Power / Model | APA- 5200 |
| 1kHz (HIA) with 0,5% THD 4Ω stereo (per channel) | 2600W |
| 8Ω stereo (per channel) | 1400 W |
| 8Ω bridge mono | 5200 W |
| Performance | |
| Frequency Response (at 1 Watt) | 20Hz-20KHz, +0-1 dB |
| Total Harmonic Distortion (THD) | <0,5%,20Hz-20KHz |
| Intermodulation Distortion 60Hz and 7 KHz at 4:1 from full rated output to -30dB | =/<0,35% |
| Slew Rate | >20V/us |
| Voltage Gain | 37dB |
| Damping Factor (8 ohms) 10 Hz-400Hz | >200 |
| Signal-to-Noise Ratio (below rated power, 20Hz to 20KHz. A-weighted) | >100dB |
| Crosstalk (below rated power)
At 1 kHz At 20 Khz |
-75dB -58dB |
| Input Sensitivity for full rated power at 8Ω | 0,775 Vor 1.4V |
| Input Impedance (nominal)
Balanced Unbalanced
|
20 K Ohms 10 K ohms |
| Construction | |
| Protection | Protection against short circuits, no-load, on/off muting, RF interface |
| Ventilation | Flow-through ventilation from front to back |
| Cooling | Internal heat sinks with forced air, Fan cooled, speed regulated, thermal protection |
| Power cord specification | Plug: 10A, 250V, Wire: 3x 1.0 mm2 |
| Chasis Size (unit mm) | 482x365x88mm |
| Net Weight | 21.6kg |
