Tecnare E8 Full-range Compact Loudspeaker

2-Way Passive speaker

1 x 8-inch LF cone, Vented box

1 x cone paper tweeter

370

E8 is a compact 2-way full-range loudspeaker system comprised of one 8-inch low frequency driver and one 25mm soft cone paper tweeter. Its exceptional axi-symmetric dispersion provides 130° coverage. The internal passive crossovers custom network minimize band overlap and well-controlled off-axis response. The cabinet is fitted with M8 threaded suspension points and Speakon® NL4 connectors. The enclosure has been made with the latest techniques ensuring a perfect and rigid construction. E8 is part of Tecnare’s E Series, a versatile family of loudspeakers for a wide variety of fixed installation applications It has been designed for use as stand-alone full-range speaker or together with a passive sub-woofer (e.g. the ESW110).

Features
Compact, vented two-way system
1 x 8-inch-LF/ 1 x cone paper tweeter
Multiple Attachment Points for maximun flexibility
Applications
Performing spaces
Gyms, museums and AV spaces
Multimedia spaces
Retail outlets
Educational Facilities

Frequency Response: 80 Hz – 18 kHz ±3dB, measured on axys
Components: 1×8” LF driver, 1 paper cone tweeter HF
Nominal Dispersions: 130°H x 130°V@-6dB points
Impedance: 8 Ohm
Axial Sensitivity: 90 dB
Calculated SPL: 110 dB continuous / 116 peak
Power Handling: 120 W AES / 240 W continuos
Dimensions (HxWxD) (millimeters/inches): 381 x 249 x 269 mm / 15″ x 9.80″ x 10.59″
Net Weight (kg/Pounds): 7,1 kg / 15.65 lbs.
Construction: 16mm birch plywood. Finished in black paint. Two recessed carrying handle.
Grille:  Powder coated perforated steel with acoustically transparent reticulated foam
