2-Way, Bi-amp/passive
1 x 14-inch LF coaxial loudspeaker, Vented box
1 x 1.4-inch HF compression driver on exponential horn
€2.100,00
Very high-SPL, compact two-way system
1 x14-inch Coaxial “point source” performance
Integrate suspension points and pole mount cup
Visually-appealing, low-profile
Side panel rubber feet for extra protection
M8 rigging insert
Stage monitor
Stand alone system
FOH Applications for mid-scale
Downfill, FrontFill or SideFill
Background music in restaurant, disco, club.
| Frequency Response: | 55 Hz – 18 kHz ±3dB, measured on axys |
| Components: | 1×14″ LF Coaxial cone driver and 1 x 3″ voice coil HF driver on exponential horn |
| Nominal Dispersion: | 40º x 60º – Fix it in wedge monitor configuration |
| Impedance: | 8 Ohm |
| Calculated SPL: | Bi-amp mode: 125dBSPL – 131dBSPL max / Passive mode: 124dBSPL -130dBSPL max |
| Power Handling: | 780 W AES / 1560 W continuous |
| Dimensions (HxWxD) (millimeters/inches): | 356,5×528,7×522 mm / 14.03″ x 20.81″ x 17.55″ |
| Net Weight (kg/Pounds): | 18 kg / 39.68 lbs |
| Construction: | 16mm birch plywood. Finished in black semi-matt textured Durawound weatherized coating. One recessed carrying handle. |
| Grille: | Powder coated perforated steel with acoustically transparent reticulated foam |
